Filter
Pleated Filter
Pleated Filter Cartridges are designed to optimize on the surface area of the PP media for higher flow rate, lower clean Delta P and longer Service life.
High-Efficiency Pleated Polypropylene (PP) Filter Cartridges provide more surface area for higher flow rate and longer life. Designed for food & bevarage, pharmaceutical, semiconductor and other demanding process applications, the all PP construction and gradient density microfibre media provide excellent removal efficiencies and high contaminant holding capacities.
Media:
Polypropylene Pleated Media.
Ratings:
0.2, 0.45, 1, 5, 10, 20, 50 µm
lengths:
9.75, 10, 20, 30, 40 inches
Diameter:
2.7 inches (6.9 cm)
Diameter:
2.7 inches (6.9 cm)
Pressure sand filter
Pressure sand filter is highly recommended for the removal of suspended & visible impurities like sand, dust particles & heavy metals etc. Our assortment of pressure sand filters finds extensive application for removing turbidity, suspended particles, color, odor and iron that are present in raw water with minimum pressure drop. We offer easy to operate pressure sand filters that give sparking clear water. The filters which are commonly used are sand and gravels or anthracite, carbon and mangenized dioxide.
The SS or stainless steel pressure sand filters find usage in:
Pharmaceutical product water
Dairy & food products
Beverages
Package drinking water
Cosmetics
Self Cleaning Filter systems
The filter system consists of a cylindrical, cleanable filter which rotates against the stationery cleaning knife causing particles larger than the opening to be retained and eventually scraped off the element.
Continuous, operator independent operation
No need for disposable filter cartridges thereby reducing the cost of replacement elements, change-out labor, and downtime.
No Operator exposure, hence no health hazzards
Unique welded wedge wire type mesh, strong, rugged and durable
Higher percentage of open area, provides significantly higher flow throughput, lower pressure drops
Removal Ratings: 25 to 500 Microns.
Optional PLC based Panels/ Flame Proof Motor
Trolley Mounted / Skid Mounted Filtration
Systems are ideal for batch filtration applications where a single unit is required to be used at different locations in a manufacturing plant. A Trolley mounted unit can be used as a viable & economical alternative to multiple permanently installed filtration systems.
A Typical trolley mounted unit consists of a complete filtration system mounted on a mobile trolley with isolation valves, provision for bye pass, pump, motor, pressure gauges and can be automated to meet individual application needs.
